"*" indicates required fields Company* Point of Contact* First Last Email* Phone*1. LOAD PIN REQUIREMENTSLoad Pin Quantity*Preferred Delivery Date* MM slash DD slash YYYY Measurement Capacity (Full Scale Calibrated Load, specify units)* Type of Loading* Static, One Way Static, Reversed Fatigue, One Way Fatigue Fully Reversed Number of Cycles Capacity Overload Requirements:* Safety Factor based on material ultimate strength Safety Factor based on material yield strength Safety FactorMeasurement Configuration (Bridge Loading):* Single-Axis Redundant (dual) Single Axis Bridges Bi-axial, Two Measurement Axes at 90° Apart (Px and Py), See Figure A Figure A2. LOAD PIN CONFIGURATIONType* Load Pin (typical) Load Pin, Figure B Load BoltLoad Bolt, Figure C 3. Load Pin Installation Layout (inches, xx.xxxx format)Ae: Width of center loading Bc: Width of side support loading Ec: Overall width of Loading section Db: Diam. of Bore Holes mating with Load Pin Dp: Diam. of Load Pin/BoltDiameter tolerances tighter than .002” may result in increased cost and lead time for grinding operations. Figure DFor load pin CAD models/drawings, please see the Custom Load Pin Configurator4. DESIGN FEATURESSpecify Connector Type* Connector Permanently Attached Cable Cable Length Specify Connector/Cable Location1-512345Specify Anti-Rotation Keeper Flat Location1-41234The Strainsert standard anti-rotation feature is a flat with anti-rotation plate as shown in Figure F. Alternate anti-rotation methods are available. Figure E Figure FAdditional Design Features Lubrication Port for sheaves/bearings Outgassing Material Restrictions Other Other 5. CALIBRATION MODE Standard Loading (P) is applied through the center loading hardware (Ae in Figure G), reacted by supports (Bc), and perpendicular to the keeper slot. (0 degree "Standard" load direction below.)Calibration* Standard (Calibrated 0°) Standard Fully Reversed (Calibrated 0° and 180°) Variable Load Direction Range of Degrees i.e. 0° to 90° Figure G6. ENVIRONMENTAL REQUIREMENTSEnvironmental Requirements* Indoor Outdoor Submerged Hydrostatic Pressure Submerged Hydrostatic Pressure Operating Temperature Range (°F)Low High Compensated Temperature Range (°F) Maximum allowable range -60° F to 300°FLow High 7. ELECTRICAL REQUIREMENTSPin Output:* mV/V (standard) 4-20mA loop powered Digital (CAN, RS232, RS-485) Wireless – T24 System Other Other 8. SPECIAL PROCESSES /QUALITY CLAUSES/ INSTRUMENTATION / CLEARANCE REQUIREMENTSInformationPlease enter any pertinent information below for special cases, design features, calibration requirements, instrumentation, and/or quality requirements. Please email (dhudson@strainsert.com or rturzanski@strainsert.com) with sketches, photos or other files. To discuss your application, call 610-825-3110.Attach Files Drop files here or Select files Max. file size: 10 MB, Max. files: 5. Note: You will receive an email which includes the content of this submission.EmailThis field is for validation purposes and should be left unchanged. Δ
